PBM Motor and Fan (Suzhou) Co., Ltd. is one of the most reliable manufacturers and suppliers of 225mm ec-dc waterproof ip55 backward curved centrifugal fan with support bracket pk3n225b48-tg0 in China. With abundant experience, we are committed to providing high quality customized products with competitive price. If you're going to buy bulk premium 225mm ec-dc waterproof ip55 backward curved centrifugal fan with support bracket pk3n225b48-tg0, welcome to get pricelist from our factory.
PPM specializes in thorough ODM and bulk delivery of medical cooling systems, as well as the development and production of superior EC/DC fans and intelligent airflow solutions. In addition to making fans, PBM offers cooling system solutions for medical imaging equipment.
General Characters
|
1-1 |
Rated Voltage |
48 VDC |
|
1-2 |
Operating Voltage |
36~57 VDC |
|
1-3 |
Rated Speed |
3000 RPM |
|
1-4 |
Input Current |
3.5 A |
|
1-5 |
Input Power |
168 W |
|
1-6 |
Air Flow |
753.28 CFM / 1280 M³/H |
|
1-7 |
Static Pressure |
3.84 inH₂O / 960 Pa |
|
1-8 |
Acoustical Noise |
72 dB(A) |
|
1-9 |
Life Expectancy |
50,000 Hours (L10) At 40℃ room, humidity 15%~65%RH. |
|
1-10 |
Insulation Class |
Class B |
|
1-11 |
Motor Protection |
Locked rotor protection Polarity protection Automatic restart capability |
|
1-13 |
Speed Control |
Control input 0~10VDC / PWM |
|
1-14 |
Protection Type |
IP55 |
|
1-15 |
Signal Output |
FG (Frequency Generator) |
Mechanical Characters
|
2-1 |
Dimension |
270 mm X 270mm X 119.6mm (see dimension drawing) |
|
2-2 |
Material of Impeller |
PA66+GF |
|
2-3 |
Number of Blades |
7 |
|
2-4 |
Bearing System |
NMB ball bearing |
|
2-5 |
Lead Wire |
Red, Blue (AWG18#); Blue(AWG18#);Yellow, White(AWG24#) |
Environmental Characters
|
3-1 |
Operating Temperature |
-25℃ to 60℃ |
|
3-2 |
Storage Temperature |
-40℃ to 75℃ |
|
3-3 |
Operating Humidity |
5% to 90% RH |
|
3-4 |
Storage Humidity |
5% to 95% RH |
Performance Curve
Testing Condition:
Input Voltage----Operating voltage (48VDC)
Temperature-----Room temperature
Humidity---------65%RH
Outline Drawing
Note:
1.Connection line: Red, Blue(AWG18#);Yellow, White(AWG24#)
2.DC: Red=Voltage Intput 24VDC, Yellow=0-10VDC/PWM, White=FG, Blue=GND;
