PBM Motor and Fan (Suzhou) Co., Ltd. is one of the most reliable manufacturers and suppliers of 120mm ec-dc single inlet blower ps3n120b24m in China. With abundant experience, we are committed to providing high quality customized products with competitive price. If you're going to buy bulk premium 120mm ec-dc single inlet blower ps3n120b24m, welcome to get pricelist from our factory.

PMB supports the development of residential air purifiers, commercial fresh air units, FFU filter units, biosafety cabinets, and cleanroom equipment by concentrating on the research and production of superior EC/DC fans and intelligent airflow solutions. In order to meet the unique requirements of manufacturers of air purification and cleanroom equipment in their standardized manufacturing processes, PBM's skilled engineering team works with production lines to offer a variety of bespoke services.

General Characters

1-1	Rated Voltage	24 VDC
1-2	Operating Voltage	16~28 VDC
1-3	Rated Speed	2800 RPM
1-4	Input Current	3.0 A
1-5	Input Power	72 W
1-6	Air Flow	186.55 CFM / 317 M³/H
1-7	Static Pressure	1.88 inH₂O / 471 Pa
1-8	Acoustical Noise	58 dB(A)
1-9	Life Expectancy	50,000 Hours (L10) At 40℃ room, humidity 15%~65%RH.
1-10	Insulation Class	Class B
1-11	Motor Protection	Locked rotor protection Polarity protection Automatic restart capability
1-13	Speed Control	Control input 0~10VDC / PWM
1-14	Protection Type	IP44
1-15	Signal Output	FG (Frequency Generator)

Mechanical Characters

2-1	Dimension	172 mm X 181 X 115 mm (see dimension drawing)
2-2	Material of Impeller	Galvanized Metal Shell
2-3	Number of Blades	34
2-4	Bearing System	NMB ball bearing
2-5	Lead Wire	DC (AWG20 #)
