PBM Motor and Fan (Suzhou) Co., Ltd. is one of the most reliable manufacturers and suppliers of φ150x918mm ac cross flow fan pc150b2a918l in China. With abundant experience, we are committed to providing high quality customized products with competitive price. If you're going to buy bulk premium φ150x918mm ac cross flow fan pc150b2a918l, welcome to get pricelist from our factory.

PBM's high‑performance cross flow fans are widely deployed across industrial, commercial, and residential ventilation, household appliances, HVAC systems, the automotive industry, telecommunications, and the healthcare and medical sectors. PBM is not merely a fan manufacturer; we are your industrial HVAC and ventilation system solution partner, fully supporting customized cross flow fan services – including length adjustments, mounting brackets, motor types, and connector options. We welcome OEM customization based on your drawings – send us your specifications, and we will deliver.

General Characters

1-1	Rated Voltage	230 VAC
1-2	Frequency	50/60 Hz
1-3	Rated Speed	900 RPM
1-4	Input Current	1.87 A
1-5	Input Power	220 W
1-6	Acoustical Noise	71 dBA
1-7	Life Expectancy	30,000 Hours At nominal supply voltage, full speed room temperature is 20℃.
1-8	Direction of Rotation	Clockwise seen on rotor
1-9	Airflow	3200 m³/H
1-10	Air Pressure	86 Pa

Mechanical Characters

2-1	Dimension	see dimension drawing
2-2	Material of Impeller	Aluminum alloy
2-3	Number of Blades	28
2-4	Bearing System	NMB ball bearing
2-5	Lead Wire	Red, Black, AWG #20
