PBM Motor and Fan (Suzhou) Co., Ltd. is one of the most reliable manufacturers and suppliers of φ50x158mm dc cross flow fan pc50b12158b in China. With abundant experience, we are committed to providing high quality customized products with competitive price. If you're going to buy bulk premium φ50x158mm dc cross flow fan pc50b12158b, welcome to get pricelist from our factory.

Its compact 50mm diameter design allows this dc cross flow fan to be easily integrated into the narrow air ducts of space-constrained devices such as embedded appliances, ultra-thin air curtains, and portable medical equipment. In medical refrigerators and laboratory incubators, it achieves uniform temperature distribution between shelves; in electric ovens and microwave ovens, it provides directional cooling for control boards and magnetrons; and in air curtains, it generates a uniform air curtain with minimal volume, effectively isolating insects and hot/cold air.

PBM provides not only fan components but also a comprehensive ventilation and cooling solution throughout the entire R&D process. From requirements analysis and prototype testing to mass delivery, the technical team provides full engineering support. Customized services cover multiple dimensions.

General Characters

1-1	Rated Voltage	12 VDC
1-2	Operating Voltage	9~15 VDC
1-3	Rated Speed	2400 RPM
1-4	Input Current	0.44 A
1-5	Input Power	5.28 W
1-6	Air Flow	64.74 CFM / 110 m³/H
1-7	Static Pressure	4.59 mmH₂O / 45 Pa
1-8	Acoustical Noise	42 dB(A)
1-9	Life Expectancy	50,000 Hours (L10) At 40℃ room, humidity 15%~65%RH.
1-10	Insulation Class	Class B
1-11	Motor Protection	Locked rotor protection Polarity protection Automatic restart capability
1-12	Speed Control	Control input 0~10VDC / PWM
1-13	Protection Type	IP44
1-14	Signal Output	FG (Frequency Generator)

Mechanical Characters

2-1	Dimension	70 mm X 70mm X 226mm (see dimension drawing)
2-2	Material of Impeller	Aluminum alloy
2-3	Number of Blades	22
2-4	Bearing System	NMB ball bearing
2-5	Lead Wire	Red, Black, White AWG22#
