PBM Motor and Fan (Suzhou) Co., Ltd. is one of the most reliable manufacturers and suppliers of φ65x520mm dc cross flow fan pc65b12520l in China. With abundant experience, we are committed to providing high quality customized products with competitive price. If you're going to buy bulk premium φ65x520mm dc cross flow fan pc65b12520l, welcome to get pricelist from our factory.

The equipment works with lots of setups. It is good for things like household appliances and business equipment. It is also good for industrial control applications. This is because it has a power supply that only uses 12V. It also gives a steady flow of air and is small. The commercial refrigeration equipment gets cooling and ventilation from this.

General Characters

1-1	Rated Voltage	12 VDC
1-2	Operating Voltage	9~15 VDC
1-3	Rated Speed	1800 RPM
1-4	Input Current	2.7 A
1-5	Input Power	32.4 W
1-6	Air Flow	414.89 CFM / 705 m³/H
1-7	Static Pressure	6.53 mmH₂O / 64 Pa
1-8	Acoustical Noise	50 dB(A)
1-9	Life Expectancy	50,000 Hours (L10) At 40℃ room, humidity 15%~65%RH.
1-10	Insulation Class	Class B
1-11	Motor Protection	Locked rotor protection Polarity protection Automatic restart capability
1-12	Speed Control	Control input 0~10VDC / PWM
1-13	Protection Type	IP44
1-14	Signal Output	FG (Frequency Generator)

Mechanical Characters

2-1	Dimension	100 mm X 112mm X 589mm (see dimension drawing)
2-2	Material of Impeller	Aluminum alloy
2-3	Number of Blades	22
2-4	Bearing System	NMB ball bearing
2-5	Lead Wire	Red, Black, White AWG22#
