PBM Motor and Fan (Suzhou) Co., Ltd. is one of the most reliable manufacturers and suppliers of 80x80x56mm ec-dc axial fan pa8056b12u in China. With abundant experience, we are committed to providing high quality customized products with competitive price. If you're going to buy bulk premium 80x80x56mm ec-dc axial fan pa8056b12u, welcome to get pricelist from our factory.

With a rated voltage of 12VDC and a high-speed operation up to 17,000 RPM, the PA8056B12U provides an airflow of 217.2m³/h and a maximum static pressure of 1642Pa, making it suitable for high-resistance cooling systems. The compact 80mm frame size and optimized axial impeller design allow easy integration into industrial equipment and electronic cooling applications.

This compact axial fan is widely used in industrial control systems, communication equipment, power electronics, medical devices, and HVAC applications where efficient heat dissipation and stable airflow performance are required. PBM provides customized EC/DC axial fan solutions with flexible options for voltage, connector, and performance requirements, supporting customers from prototype validation to mass production.

General Characters

1-1	Rated Voltage	12 VDC
1-2	Frequency	/
1-3	Operating Voltage	7～13.2 VDC
1-4	Rated Speed	17000 RPM
1-5	Input Current	6.8 A
1-6	Input Power	81.6 W
1-7	Airflow	217.2 M³/H
1-8	Static Pressure	1642 Pa
1-9	Acoustical Noise	79.5 dB(A)
1-10	Life Expectancy	50,000 Hours(L10) At 40℃ room,humidity 15%～65%RH.
1-11	Insulation Class	Class A
1-13	Motor Protection	/
1-14	Speed Control	/
1-15	Protection Type	/
1-17	Signal Output	/
