Delivering 24V DC rated voltage and IP55‑rated fully sealed construction, this high static pressure DC blower for robot vacuum and industrial dust collector fan ensures reliable, energy‑saving operation across all load conditions. PBM provides full engineering support from demand analysis and selection evaluation through prototype testing to mass production. Our OEM customization services cover multiple dimensions – including custom lead wire configurations, compact size adaptations, and optional silencer accessories – tailored specifically for cleaning appliances, industrial dust extraction, and other specialized applications. Whether you need a 640 Pa centrifugal fan for floor scrubber or a custom IP55 blower for vacuum pickup systems, PBM delivers precision‑engineered solutions for your unique requirements.
General Characters
|
1-1 |
Rated Voltage |
24 VDC |
|
1-2 |
Operating Voltage |
16~28 VDC |
|
1-3 |
Rated Speed |
2400 RPM |
|
1-4 |
Input Current |
2.8 A |
|
1-5 |
Input Power |
67.2 W |
|
1-6 |
Air Flow |
205.98 CFM / 350 M³/H |
|
1-7 |
Static Pressure |
2.56 inH2O / 640 Pa |
|
1-8 |
Acoustical Noise |
67 dB(A) |
|
1-9 |
Life Expectance |
50,000 Hours(L10) At 40℃ room, humidity 15%~65%RH. |
|
1-10 |
Insulation Class |
Class B |
|
1-11 |
Motor Protection |
Locked rotor protection Polarity protection Automatic restart capability |
|
1-13 |
Speed Control |
Control input 0~10VDC / PWM |
|
1-14 |
Protection Type |
IP55 |
|
1-15 |
Signal Output |
FG (Frequency Generator) |
Mechanical Characters
|
2-1 |
Dimension |
172 mm X 181 mm X 115 mm(see dimension drawing) |
|
2-2 |
Material of Impeller |
Cold rolled steel sheet |
|
2-3 |
Number of Blades |
34 |
|
2-4 |
Bearing System |
NMB ball bearing |
|
2-5 |
Lead Wire |
Red, Blue(AWG18#);Yellow, White(AWG24#)
|
Environmental Characters
|
3-1 |
Operating Temperature |
-25℃ to 60℃ |
|
3-2 |
Storage Temperature |
-40℃ to 75℃ |
|
3-3 |
Operating Humidity |
5% to 90% RH |
|
3-4 |
Storage Humidity |
5% to 95% RH |
Performance Curve
Testing Condition:
Input Voltage----Operating voltage (24VDC)
Temperature-----Room temperature
Humidity---------65%RH
Outline Drawing
Note:
1.Connection line: Red, Blue(AWG18#);Yellow, White(AWG24#)
2.DC: Red=Voltage Intput 24VDC, Yellow=0-10VDC/PWM, White=FG, Blue=GND;
