Ø30mm EC-DC Cross-Flow Fan PC3N30B24T Ø30mm EC-DC Cross-Flow Fan PC3N30B24T

PBM FOCUS ON EC FAN ONLY. Certificate: CE,UL,ROHS; Supply Ability: 100,000 pcs per year; MOQ: 1~999 pcs based on EXW price; 1000 pcs above based on FOB price.

Share this:

Technical Description

General Characters

1-1

Rated Voltage

24 VDC

1-2

Operating Voltage

16~28 VDC

1-3

Rated Speed

25500 RPM

1-4

Input Current

0.2 A

1-5

Input Power

4.8 W

1-6

Air Flow

250.11 CFM / 4255 m3/H

1-7

Static Pressure

0.0832 inH2O / 20.8 Pa

1-8

Acoustical Noise

40 dB(A)

1-9

Life Expectance

50,000 Hours(L10)

At 40℃ room, humidity 15%~65%RH.

1-10

Insulation Class

Class B

1-11

Motor Protection

Locked rotor protection

Polarity protection

Automatic restart capability

1-13

Speed Control

Control input 0~10VDC / PWM

1-14

Protection Type

IP44

1-15

Signal Output

FG (Frequency Generator)



Mechanical Characters

2-1

Dimension

47mm X 46mmX 1010mm (see dimension drawing)

2-2

Material of Impeller

Steel

2-3

Number of Blades

22

2-4

Bearing System

NMB ball bearing

2-5

Lead Wire

Red , Black, White AWG22#



Environmental Characters

3-1

Operating Temperature

-25℃ to 60℃

3-2

Storage Temperature

-40℃ to 75℃

3-3

Operating Humidity

5% to 90% RH

3-4

Storage Humidity

5% to 95% RH





Curve and Draw

Performance Curve





Testing Condition:

Input Voltage----Operating voltage (24VDC)

Temperature-----Room temperature

Humidity---------65%RH



Outline Drawing



Note:

Connection line 3X (Red, Black, White AWG22#);

Red=+, White=0-10VDC/PWM, Blue=GND.
