160mm Waterproof IP55 EC-AC Single Inlet Blower PS3N160B2E-TP0

160mm Waterproof IP55 EC-AC Single Inlet Blower PS3N160B2E-TP0

PBM FOCUS ON EC FAN ONLY. Certificate: CE,UL,ROHS; Supply Ability: 100,000 pcs per year; MOQ: 1~100 pcs based on EXW price; 100 pcs above based on FOB price.

Technical Description

Curve and Draw

Certificate

Application Scopes

Packing Details

PS3N160B2E-TP0 is a 160mm EC Single Inlet Blower made especially for Single Room Ventilation Duct Fan Unit. It covers a variety of commercial and residential central air conditioning terminal equipment, including duct-type air handling units, inverter-driven duct units, medium/high-static-pressure duct-connected units, and indoor units for central air conditioning systems.
When compared to ordinary AC fans under partial load situations, it achieves energy savings of more than 30% thanks to its high-efficiency EC motor, which significantly outperforms standard AC induction motors. Its 0–10 VDC/PWM dual-mode stepless speed control allows for real-time airflow modification based on the duct-type air conditioning system's air supply needs and terminal static pressure. This guarantees energy savings and accurate, on-demand air delivery, especially in multi-zone duct systems where it successfully avoids cooling capacity waste brought on by "over-delivery." It maintains steady airflow even under high static pressure levels of 950 Pa because of its improved aerodynamic design and 38-blade cold-rolled steel forward-curved impeller. In ducted air conditioning systems, it easily gets over obstacles, including lengthy ducts, elbow bends, and clogged filters.

Intelligent airflow systems and premium EC/DC fans are PBM's areas of expertise. The fans enable interaction with building automation systems for remote monitoring by supporting speed signal output (FG). We provide OEM customization services, such as silencer accessories, improved protection, corrosion-resistant surface treatments, and AC three-pin/DC four-pin wiring. PBM is your go-to expert for duct-type air conditioning, ventilation, and air purification services.

General Characters

1-1	Rated Voltage	230 VAC
1-2	Frequency	50/60 Hz
1-3	Operating Voltage	184~270 VAC
1-4	Rated Speed	2000 RPM
1-5	Input Current	1.2 A
1-6	Input Power	170 W
1-7	Air Flow	388.41 CFM / 660 M³/H
1-8	Static Pressure	3.80 inH₂O / 950 Pa
1-9	Acoustical Noise	67 dB(A)
1-10	Life Expectancy	50,000 Hours (L10) At 40℃ room, humidity 15%~65%RH.
1-11	Insulation Class	Class B
1-13	Motor Protection	Locked rotor protection Polarity protection Automatic restart capability
1-14	Speed Control	Control input 0~10VDC / PWM
1-15	Protection Type	IP55
1-17	Signal Output	FG (Frequency Generator)

Mechanical Characters

2-1	Dimension	220 mm X 245 mm X 130 mm (see dimension drawing)
2-2	Material of Impeller	PA66+GF
2-3	Number of Blades	38
2-4	Bearing System	NMB ball bearing
2-5	Lead Wire	AC (AWG20#), DC (AWG24#)
